Specifications

Imaging & Display

• IR Resolution: 160 × 120 pixels

• Display: 3 in. LCD, 320 × 240 pixels, backlit

• Built-in Digital Camera: 640 × 480 pixels

• Field of View (FOV): 47° × 35°

• Digital Camera FOV: 73° × 61°, adapts to IR lens

• f-number: 1.1

• Focal Length: 1.9 mm (0.075 in.)

• Focus: Fixed

• Depth of Field: 0.1 m (0.33 ft.) to infinity

• Image Frequency: 9 Hz

• Multi Spectral Dynamic Imaging (MSX): Yes

• Spectral Range: 7.5–13 µm

• Thermal Sensitivity/NETD: <100 mK @ 30°C (86°F)

• Spatial Resolution (IFOV): 6.22 mrad

• Pitch: 12 µm

Image Modes

• Basic fire-fighting (default)

• Black-and-white fire-fighting

• Fire mode

• Search-and-rescue mode

• Heat detection mode

• Cold detection mode

• Building analysis mode

Measurement & Analysis

• Accuracy: ±4°C (±7.2°F) or ±4% (10–35°C / 50–95°F ambient)

• Auto Range: Auto, non-selectable

• Automatic Hot Detection: Hottest 20% of scene is colorized

• Isotherm: Yes

• Spot Meter: 1.0

• Object Temperature Range:

  • –20°C to 150°C (–4°F to 302°F)

  • 0°C to 500°C (32°F to 932°F)

Environmental & Certifications

• Operating Temperature Range: –10°C to 55°C (14°F to 131°F); short-term up to 260°C (500°F)

• Storage Temperature Range: –40°C to 70°C (–40°F to 158°F)

• Relative Humidity: 95% (25–40°C / 77–104°F, non-condensing)

• Corrosion: ASTM B117, salt spray, 5% saline, 48 hours at 35°C

• Drop: 2 m (6.6 ft.)

• Shock: 25 g (IEC 60068-2-27)

• Vibration: 2 g (IEC 60068-2-6)

• Humidity (Operating & Storage): IEC 60068-2-30, 24h, 95% RH, 2 cycles

• Magnetic Fields: EN 61 000-4-8, test level 5

• Encapsulation: IP67 (IEC 60529)

• EMC: EN 61000-6-2:2005, EN 61000-6-3:2011, FCC 47 CFR Part 15 B

Power

• Battery Type: Li-ion

• Capacity: 2.6 Ah at 20–25°C (68–77°F)

• Operating Time: ~4 hours at 25°C with typical use

• Voltage: 3.6 V

• Battery Weight: 0.119 kg (0.26 lb.)

• Charging System: In-camera or dedicated charger

• Charging Time: 2.5 h to 90% (LED status indicators)

• Charging Temperature: 0–45°C (32–113°F)

• Power Management: Auto shutdown and sleep mode

• Safety: CE/EN/UL/CSA/PSE 60950-1

• Start-Up Time: 30 seconds

• From Sleep Mode: 10 seconds

Physical

• Camera Size (L × W × H): 250 × 105 × 90 mm (9.8 × 4.1 × 3.5 in.)

• Camera Weight (incl. battery): 0.7 kg (1.54 lb.)

• Packaging Size: 323 × 325 × 110 mm (12.7 × 12.8 × 4.3 in.)

• Tripod Mounting: UNC 1/4"-20

• Materials: PPSU, silicone rubber, cast aluminum, flame-resistant magnesium alloy

User Interface

• Display: 3 in. LCD, 320 × 240 pixels, backlit

Communication & Data Storage

• Interface: Update from PC devices

• USB: Micro-B

• Image Storage: N/A

Software

• Compatible with FLIR Tools®
