Specifications

Imaging & Display

• IR Resolution: 240 × 180 pixels

• Display: 4 in. LCD, 320 × 240 pixels, backlit

• Field of View (FOV): 51° × 38°

• f-number: 1.25

• Focal Length: 9 mm (0.35 in.)

• Focus: Fixed

• Depth of Field: 0.84 m to infinity (33 in. to infinity)

• Detector Type: Focal plane array (FPA), uncooled microbolometer

• Image Frequency: 60 Hz

• Pitch: 25 µm

• Spatial Resolution (IFOV): 3.6 mrad

• Spectral Range: 7.5–13 µm

• Thermal Sensitivity/NETD: <40 mK @ 30°C (86°F)

• Zoom: 2× digital zoom

• Contrast Optimization: Digital image enhancement using FSX

• Non-radiometric IR Video Streaming: Uncompressed colorized video via USB

Image Modes

• IR image

• TI Basic fire-fighting mode

• Black-and-white fire-fighting mode

• Fire mode

• Search-and-rescue mode

• Heat detection mode

• Thumbnail gallery

Measurement & Analysis

• Accuracy: ±4°C (±7.2°F) or ±4% of reading (10°C to 35°C / 50°F to 95°F)

• Auto Range: Yes, selectable on/off using FLIR Tools®

• Automatic Hot Detection: Heat detection mode (hottest 20% of scene is colorized)

• Isotherm: Yes

• Spot Meter: 1.0

• Object Temperature Range:

  • –20°C to 150°C (–4°F to 302°F)

  • 0°C to 650°C (32°F to 1202°F)

• Set-up Commands: Local adaptation of units, date, and time formats

Environmental & Certifications

• Operating Temperature Range:

  • –20°C to 60°C (–4°F to 140°F): continuous

  • 150°C (302°F): 15 minutes

  • 260°C (500°F): 5 minutes

• Storage Temperature Range: –40°C to 85°C (–40°F to 185°F)

• Relative Humidity: 95% (25–40°C / 77–104°F, non-condensing)

• Drop: 2 m (6.6 ft.) on concrete (IEC 60068-2-31)

• Shock: 25 g (IEC 60068-2-27)

• Vibration: 2 g (IEC 60068-2-6)

• Humidity (Operating & Storage): IEC 60068-2-30, 24 h at 95% RH, 2 cycles

• Magnetic Fields: EN 61000-4-8, Test level 5 (severe industrial environment)

• Encapsulation: IP67 (IEC 60529)

• EMC: EN 61000-6-2:2005, EN 61000-6-3:2011, FCC 47 CFR Part 15 B

Power

• Battery Type: Li-ion

• Capacity: 6.2 Ah at 20–25°C (68–77°F)

• Operating Time: >5 hours at 25°C with typical use

• Voltage: 3.6 V

• Battery Weight: 0.152 kg (0.3 lb.)

• Charging System: In-camera charging, 2-bay charger, optional in-truck charger

• Charging Time: 2 h to 85% capacity (LED indicators)

• Charging Temperature: 0–45°C (32–113°F)

• Power Management: Auto shutdown and sleep mode

• Safety: CE/EN/UL/CSA/PSE 60950-1

• Start-Up Time: <17 seconds (IR image, no GUI)

• From Sleep Mode: <4 seconds

Physical

• Camera Size (L × W × H): 120 × 125 × 280 mm (4.7 × 4.9 × 11 in.)

• Camera Weight (incl. battery): 1.1 ±0.05 kg (2.4 ±0.1 lb.)

• Packaging Size: 500 × 190 × 370 mm (19.7 × 7.5 × 14.6 in.)

• Tripod Mounting: UNC ¼"-20 (adapter required)

• Materials: PPSU, silicone rubber, cast aluminum, flame-resistant magnesium alloy

User Interface

• Display: 4 in. LCD, 320 × 240 pixels, backlit

• Languages: English

• Report Generation: With FLIR Tools software

Communication & Data Storage

• File Formats: Standard JPEG

• Image Storage: Standard JPEG; image freeze configurable

• Storage Capacity: Up to 200 images

• Storage Mode: IR only

• Storage Media: Internal flash memory

• Interface: PC updates, data transfer to/from PC

• USB: USB Mini-B

Software

• Compatible with FLIR Tools®
